Features of the unit

1. The air conditioner gathered temperature, humidity and CO2 control as a whole unit.

2. Temperature and humidity sensor using the enthalpy difference air-conditioner laboratory dedicated wet and dry bulb thermometer, temperature measurement error is less than 0.1 DEG C, the test error of humidity is less than 2%, fundamentally put an end to the electronic temperature hygrometer in moist environment is easy to be damaged and the problem of big error test.

3. The unit adopts double coil and four pipe design, the hot and cold water circulates independently, so as to meet the heating and cooling purpose for a plurality of mushroom growing rooms in different seasons and dehumidification before the mushroom
harvest.

4. The unit adopts frequency motor, not only air volume adjusting range of 10% to 100%, but also make the growing room bas been in a state of air circulation, keep the temperature, humidity and CO2 of each point in the room uniform.

5. Fresh air valve and air return valve used in all proportional actuator, adjusting range from 0~100%, according to the CO2 concentration of the air valve need to carry out stepless regulation.

6. The fresh air inlet by initial effect + bag filter, effectively avoid the infection of the outside air to the mushroom rooms.

7. The unit with filter pressure difference alarm, automatic remind customers of filter cleaning or replacement.

8. The centrifugal fan adopts an external installation, not only convenient maintenance, but also avoids the influence of the mushroom room steam high temperature disinfection for fan motor.

9. The unit frame is made of stainless steel, the box body adopts the magnesium alloy plate, put an end to all of the units of the corrosion factors.

10. The hot and cold water can use proportional electric valve according to the temperature by adjusting the PID.
